Product Details:
|
| Control System: | PLC | Cooling Method: | Air Cooling And Water Cooling |
|---|---|---|---|
| Extrusion Capacity: | 250kg/h | Material: | PET |
| Band Width: | 6-20mm | Screw L/D Ratio: | 30:1 |
| Screw Speed: | 0-100rpm | Voltage: | 380V/50Hz |
| Warranty: | 1 Year | Condition: | New |
Plastic package band belt making machine PET Packing Strap PET Strapping Band Extrusion Machine
This production line is designed to produce automatic pet straping belt with full recyled PET bottle flakes or PET granules. As PET materials have water absorption becomes brittle and automatic strap needs to be high quality, the machine needs good design and high precison production. Qingdao Wings Plastic Technology Co.,Ltd is proffesional manufacturer of the PET strap production line.
Our company this line adopt the PLC control the whole line do the automatic production. It use the melting pump and pressure sensor ensure the production stable and strap quality control.
The raw material you can use 100% recycled PET flakes from the waste PET bottles, or virgin material or mixed with each other.
Production Flow:
Materials feeding -- Pre-crystallization -- Drying -- Feeding -- Extruder melt -- Filter -- Melt metering pumb -- Extrusion die -- Hot water tank --Five Pulling rollers -- Stretching Oven -- Stretching rollers -- Embossing --Annealing treatment oven and water tank -- Three Pulling Rollers -- Winders -- Packing
| Name | Strap Cavities | Motor | Screw Diameter | Screw L:D | Output | Screw Speed |
| SJ90/33 | 1-2 Cavities | 75kw | 90mm | 33:1 | 150-250kg/h | 72RPM |
| SJ100/33 | 1-3 Cavities | 90kw | 100mm | 33:1 | 250-300kg/h | 72RPM |
| SJ120/33 | 2-4 Cavities | 110kw | 120mm | 33:1 | 300-400kg/h | 72RPM |
