Electric Pe Pipe Production Line HDPE LDPE PP Corrugated Pipe Extrusion Machine

Certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
I'm Online Chat Now

Electric Pe Pipe Production Line HDPE LDPE PP Corrugated Pipe Extrusion Machine

Electric Pe Pipe Production Line HDPE LDPE PP Corrugated Pipe Extrusion Machine
Electric Pe Pipe Production Line HDPE LDPE PP Corrugated Pipe Extrusion Machine
Electric Pe Pipe Production Line HDPE LDPE PP Corrugated Pipe Extrusion Machine Electric Pe Pipe Production Line HDPE LDPE PP Corrugated Pipe Extrusion Machine Electric Pe Pipe Production Line HDPE LDPE PP Corrugated Pipe Extrusion Machine Electric Pe Pipe Production Line HDPE LDPE PP Corrugated Pipe Extrusion Machine Electric Pe Pipe Production Line HDPE LDPE PP Corrugated Pipe Extrusion Machine Electric Pe Pipe Production Line HDPE LDPE PP Corrugated Pipe Extrusion Machine Electric Pe Pipe Production Line HDPE LDPE PP Corrugated Pipe Extrusion Machine

Large Image :  Electric Pe Pipe Production Line HDPE LDPE PP Corrugated Pipe Extrusion Machine

Product Details:
Place of Origin: Qingdao China
Brand Name: WingsPlastic
Certification: CE
Model Number: SJ45/33
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wooden Box or Film Packing
Delivery Time: 45 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10 sets

Electric Pe Pipe Production Line HDPE LDPE PP Corrugated Pipe Extrusion Machine

Description
Condition: New Powder Condition: 380V/50HZ Or Customized
Capacity: 40-80kg/h Or Customized Pipe Diameters: 10-50mm Or Customized
Suitable Materials: HDPE LDPE EVA PVC PA
High Light:

50HZ Pe Pipe Production Line

,

Pe Pipe Production Line LDPE

,

LDPE Pp Corrugated Pipe Extrusion Machine

Qingdao machinery , plastic machine for pe / pp corrugated pipe extruder machine

The quality is stable, and can keep running at a high speed.Under the control of the water cooling and air cooling, linear velocity can reach 12-20 meters per minute, corrugated pipe forming machine can be equipped with 72 pairs of modules.

PE / PP corrugated pipe machine

PE / PP corrugated pipe extrusion line

PE / PP corrugated pipe extruder

PE / PP corrugated pipe production line

Plastic single wall corrugated pipe machine Process line: Raw material + master batches→mixing→vacuum feeding →material dryness →single screw extruder→extrusion mould→corrugation forming machine→meter measurer→double winder→finished product inspecting &packing

Plastic single-wall corrugated pipes have feathers of high temperature resistance,resistant to corrosion and abrasion,high intensity,good flexibility,etc.

They are widely used in fields of auto wire, electric thread-passing pipes, circuit of machine tool, protective pipes of lamps and lanterns wire, tubes of air conditioner and washing machine, etc.

Extruder SJ 30/25 SJ 45/33 SJ 65/30 SJ 65/33
Main motor power 5.5kw 11-18.5kw 30-45kw 55kw
Molding 52pairs 45-72pairs 50-72pairs 55pairs
Pipe diameter 4-17mm 10-35mm 40-110mm 72-200mm
Speed 5-15m/min 15-20m/min 10-20m/min 3-15m/min
Output 15kg/h 60-100kg/h 100-150kg/h 100-180kg/h

Electric Pe Pipe Production Line HDPE LDPE PP Corrugated Pipe Extrusion Machine 0
