Product Details:
Place of Origin: Qingdao China
Brand Name: WingsPlastic
Certification: CE
Model Number: SJ45/33
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wooden Box or Film Packing
Delivery Time: 45 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10 sets

10-32mm Single Wall Corrugated Pipe Extruder Machine PP PVC PE Pipe Making Machine

Description
Condition: New Powder Condition: 380V/50HZ Or Customized
Capacity: 40-80kg/h Or Customized Pipe Diameters: 10-50mm Or Customized
Suitable Materials: HDPE LDPE EVA PVC PA
High Light:

10mm Single Wall Corrugated Pipe Extruder Machine

,

Corrugated Pipe Extruder Machine LDPE

,

32mm LDPE Pipe Making Machine

10-32mm Single Wall Corrugated Pipe Extruder Machine

PA/PE/PP/PVC single wall corrugated pipe production line
Specializing in supply plastic corrugated pipe production line, our factory is specialized in the production of plastic corrugated pipe production line in shandong area, the advantages of plastic corrugated pipe production line;Production speed, the fastest in the industry, plastic single-wall corrugated pipe machine, low noise, convenient and easy to operate, single wall corrugated pipe mold, free debugging, training technical personnel. To provide technical support for the original manufacturer, plastic corrugated pipe production line, compact structure, simple operation, multi-usage. High ring stiffness, small friction coefficient, long life ageing resistance, corrosion resistance, good flexibility. The company promises to ensure product quality and after-sales service.

Application :

Single wall corrugated pipe can be widely used in golf course, playgrounds as light load of drainage, floods; Interior decoration wire casing; Automotive wire casing; Prestressed anchor cable casing; Air conditioner drain, etc.

This corrugated pipe production line can be used to produce single-wall or one wall corrugated pipes of PE,PP,PVC,EVA continuously,as well as PA corrugated pipes. Plastic single-wall corrugated pipes have features of high temperature resistance, resistant to corrosion and abrasion, high intensity, good flexibility, etc. They are widely used in fields of auto wire, electric thread-passing pipes, circuit of machine tool, protective pipes of lamps and lanterns wire, tubes of air conditioner and washing machine, etc.
Plastic single-wall corrugated pipe production line developed by our company adopts gears to run moulds and templates so as to realize water circulating cooling and air cooling of the products, which ensures high-speed molding, even corrugation, smooth inner and outer pipe wall. These corrugated pipes are especially used as wires of the up-market cars.



Process flow:

Raw material + master batches → mixing → vacuum feeding → material dryness → single screw extruder → extrusion mould → corrugation forming machine → meter measurer→ double winder → finished product inspecting & packing

This plastic corrugated pipe line equips with high quality machines in the whole line, with good equipments, the plastic corrugated pipe line can produce pipes stable and fast. Also all these machines share a ling service life which reduces buyer's cost.

Line Model Extruder model Production scope Output Total Power Production speed
PE-40 SJ-45/30 Φ6-40mm 60kg/h 25KW 6-10m/min
PE-63 SJ-65/30 Φ12-63mm 80kg/h 30KW 6-10m/min
PA-40 SJ-45/28 Φ6-40mm 60kg/h 25KW 6-10m/min
PVC-50 SJ51/105 Φ16-50mm 100kg/h 27KW 6-10m/min
