250kg/H PET Band Extrusion Machine Plastic Strap Belt Making Machine

Certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
I'm Online Chat Now

250kg/H PET Band Extrusion Machine Plastic Strap Belt Making Machine

250kg/H PET Band Extrusion Machine Plastic Strap Belt Making Machine
250kg/H PET Band Extrusion Machine Plastic Strap Belt Making Machine 250kg/H PET Band Extrusion Machine Plastic Strap Belt Making Machine 250kg/H PET Band Extrusion Machine Plastic Strap Belt Making Machine 250kg/H PET Band Extrusion Machine Plastic Strap Belt Making Machine 250kg/H PET Band Extrusion Machine Plastic Strap Belt Making Machine 250kg/H PET Band Extrusion Machine Plastic Strap Belt Making Machine

Large Image :  250kg/H PET Band Extrusion Machine Plastic Strap Belt Making Machine

Product Details:
Place of Origin: Qingdao China
Brand Name: WingsPlastic
Certification: CE
Model Number: SJ90/33
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wooden Box or Film Packing
Delivery Time: 45 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10 sets

250kg/H PET Band Extrusion Machine Plastic Strap Belt Making Machine

Description
Condition: New Powder Condition: 380V/50HZ Or Customized
Capacity: 250kg/h Or Customized Band Width: 6-20mm Or Customized
Suitable Materials: Pet Materials Speed: 1-5m/min
Screw: Single Screw HS Code: 84772090
Origin: Qingdao China After-sales Service: 1 Year
High Light:

250kg/H PET Band Extrusion Machine

,

PET Band Extrusion Machine 50HZ

,

50HZ Plastic Belt Making Machine

Plastic Packing Belt Making Machine PET Band Extusion Machine



PET strap is a popular materials in the world, it is always recyled bottle flakes.

This production line is designed to produce automatic pet straping belt with full recyled PET bottle flakes. As PET materials have water absorption becomes brittle and automatic strap needs to be high quality, the machine needs good design and high precison production.  Qingdao Wings Plastic Technology Co.,Ltd is proffesional manufacturer of the PET strap production line.



Our PET strap machinery advantages:

1. Energy-saving circulating air crystallization drying units, automatic control by PLC units.

2. Single screw extruder design for stable extrusion with PET flakes materials.

3. Included melt pumb pressure control units. It could ajust the extruder screw speed automaticly according the extrusion pressure.

4. Gear driven units stretching rollers. Strong and long service life.

5. Torque ajustable winders. Easy ajustment.

6. High stability heating ovens to ensure pet strap in right stretching rate and making good annealing treatment


250kg/H PET Band Extrusion Machine Plastic Strap Belt Making Machine 0
Production Flow:
Materials feeding -- Pre-crystallization -- Drying -- Feeding -- Extruder melt -- Filter -- Melt metering pumb -- Extrusion die -- Hot water tank --Five Pulling rollers -- Stretching Oven -- Stretching rollers -- Embossing --Annealing treatment oven and water tank -- Three Pulling Rollers -- Winders -- Packing




Basic Informations of Production Line:

Name Strap Cavities Motor Screw Diameter Screw L:D Output Screw Speed
SJ90/33 1-2 Cavities 75kw 90mm 33:1 150-250kg/h 72RPM
SJ100/33 1-3 Cavities 90kw 100mm 33:1 250-300kg/h 72RPM
SJ120/33 2-4 Cavities 110kw 120mm 33:1 300-400kg/h 72RPM



250kg/H PET Band Extrusion Machine Plastic Strap Belt Making Machine 1
