Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine

Certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
I'm Online Chat Now

Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine

Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine
Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine
Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine

Large Image :  Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine

Product Details:
Place of Origin: QINGDAO CHINA
Brand Name: WINGS PLASTIC
Certification: CE
Model Number: SJ65/33
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wooden Box or Film Packing
Delivery Time: 45 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 sets

Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine

Description
Control System: PLC Control Cooling Method: Air Cooling And Water Cooling
Material: PVC Max Output: 250kg/h
Screw Diameter: 50-160mm Screw Speed: 0-74rpm
Voltage: 380V/50Hz/3Phase Speed: 1-5 M/min
Condition: New Extruder: Counter-rotating Conical Twin-screw

Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic Pvc Pipe Making Machine

Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine 0

PVC Plastic pipe making machine is mainly used in the production of Agricultural water supply & water discharge system, architectural water supply & discharge system, wire laying system, etc. purposes. >>The unit consists of Conical (Parallel) double screw extruder-PVC pipe mold-Vacuum forming tank-Haul-off machine-Cutting machine-Stacker/Belling machine. >>And the line can be equipped with Comptroller thickening instrument or computer ink-jet printer, etc. to achieve the production and manufacture of high-grade tubing.


Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine 1



Our extrusion line can produce the PVC pipe with diameter from 16mm to 630mm

PVC pipe machine Line list

Pipe Range 16-40mm
(double)
20-110mm 50-250mm 160-400mm 315-630mm
Extruder SJZ65/132
Or
SJZ51/105
SJZ65/132 SJZ65/132
Or
SJZ80/156
SJZ80/156 SJZ92/188
Motor(KW) 37KW
or
18.5KW
37KW 37KW
Or
55KW
55KW 110KW
Capacity(KG/H) 80-180 150-250 150-350 200-360 400-600
Lineal speed(M/min) 1-15 1-12 0.3-6 0.2-2 0.1-1




Machine Layout

Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine 2

Production Process

PVC powder + additive — mixing—material feeder—twin screw extruder—mould and calibrator—vacuum forming machine—spraying cooling machine—haul-off machine—cutting machine—discharge rack or pipe belling machine.

Details Image



Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine 3

Final Product & Application

Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine 4Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine 5



Plastic Extruder CPVC UPVC Pipe Extrusion Line HDPE PPR PP PVC Plastic PE Pipe Making Machine 6
