Product Details:
|
| Condition: | New | Powder Condition: | 380V/50HZ Or Customized |
|---|---|---|---|
| Capacity: | 150-220kg/h Or Customized | Pipe Diameters: | 20-110mm Or Customized |
| Suitable Materials: | HDPE PPR LDPE LLDPE | ||
| High Light: | 110mm PPR Pipe Production Line,PPR Pipe Making Machine 20mm,LLDPE PPR Pipe Making Machine |
||
Qingdao City PE PP PPR pipe production line / extrusion machine / PPR pipe making machinery
Production Flow:
Raw materials+color masterbatch → mixing → vacuum feeding → raw material drying → single screw extruder → color wire extruder → spiral mold → sizing sleeve → spray vacuum shaping box → spray cooling water tank → spray coding machine → track traction machine → finished product inspection and packaging.
The PP-R drinking water pipe system is a widely used new product that uses homogeneous fusion technology in cold and hot water transportation projects. Its comprehensive technical performance and economic indicators are far superior to other similar products, especially its excellent hygiene performance. From production and use to disposal, the entire process can meet extremely high hygiene and environmental requirements. The product has advantages such as heat resistance, pressure resistance, insulation and energy conservation, long service life, and economy.
Machinery Basic Informations:
| Extruder Size | Main Motor | Max Capacity | Pipe Diamter |
| 65/33 | 37kw | 150kg/h | 16-63mm |
| 65/33-H | 45kw | 180kg/h | 16-63mm |
| 65/33-H | 55kw | 200kg/h | 20-110mm |
