Full Automatic Sandwich Straps Pp Packing Strap Production Line Mini Extrusion Strapping Band Machine

Full Automatic Sandwich Straps Pp Packing Strap Production Line Mini Extrusion Strapping Band Machine
Full Automatic Sandwich Straps Pp Packing Strap Production Line Mini Extrusion Strapping Band Machine Full Automatic Sandwich Straps Pp Packing Strap Production Line Mini Extrusion Strapping Band Machine Full Automatic Sandwich Straps Pp Packing Strap Production Line Mini Extrusion Strapping Band Machine Full Automatic Sandwich Straps Pp Packing Strap Production Line Mini Extrusion Strapping Band Machine

Large Image :  Full Automatic Sandwich Straps Pp Packing Strap Production Line Mini Extrusion Strapping Band Machine

Product Details:
Place of Origin: CHINA
Brand Name: WINGS
Certification: CE ISO
Model Number: SJ
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD30000-50000/set
Packaging Details: wooden case or container
Delivery Time: 30-45 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, Paypal
Supply Ability: 20 sets per month

Full Automatic Sandwich Straps Pp Packing Strap Production Line Mini Extrusion Strapping Band Machine

Description
Screw Design: Single-screw Screw Material: 38CrMoAlA
Motor: China Top Brand Temperature Controller: Omron Brand
Contactor: Siemens Contactor Inverter: Delta Brand
Screw L/D Ratio: 30:1 Final Product: PET Strapping Band
High Light:

Mini Extrusion Strap Production Line

,

Full Automatic Strap Production Line

Machine Advantage
1. Special design of the screw extrusion technology can be choosing as per customer needs.
2. Can process 100% recycled PP/PET bottle flakes or pellets.
3. Plasticization and stable extrusion can with PLC automatic control for the full line.
4. According different requirements, changing materials for make strap have better and special function. For example, the strap for packing cotton can be from enhancing the breaking strength and joint strength when welding strap.
5. Melt filter with two pistons with air venting design and back flushing.
6. Number of strap:1,2,4,6,Width: 5mm-22mm,Thickness: 0.5mm-1.5mm
7. Workers: 2 -3 workers per shift, 12 hours/shift.

PP PET packing strap extrusion machine include:
1. The raw material will be dried by the dehumidifier, and the below 40 dew point make the material humidity less than 40PPM, and condensation polymerization(this is for PET straping line);
2. The conveyor of the raw is in a enclosed and circular mode, and without contacting with the air, in order to made perfect effect of drying;
3. Special designed extruder screw for PP/PET production, bear the better performance of material separating and mixing. Automatic material feeding provide the smooth environment for the PP/PET strap production.
4. Special designed extrusion die & mould; And the improved screen changer realize non-stop screen changing, and without material leakage; Wedo also equitp the melting pump to ensure the packing strap material out more everage.
5. Water tank cooling the PET strap band. The steady water temperature enhance of the molecular tension strength(better equip water chiller);
6. Heating cabinet is used for thermal annealing, relief the band distortion after long-time storage;
7. Double-station automatic winder, easy operation; We provide our worldwide customer the turn-key project. We will assist our customer from the installation to the final production of this line.

Full Automatic Sandwich Straps Pp Packing Strap Production Line Mini Extrusion Strapping Band Machine 0
