PE Pipe Extruder Machine SJ65 HDPE PPR Conduit Pipe Making Machine

PE Pipe Extruder Machine SJ65 HDPE PPR Conduit Pipe Making Machine
PE Pipe Extruder Machine SJ65 HDPE PPR Conduit Pipe Making Machine PE Pipe Extruder Machine SJ65 HDPE PPR Conduit Pipe Making Machine PE Pipe Extruder Machine SJ65 HDPE PPR Conduit Pipe Making Machine PE Pipe Extruder Machine SJ65 HDPE PPR Conduit Pipe Making Machine PE Pipe Extruder Machine SJ65 HDPE PPR Conduit Pipe Making Machine

Large Image :  PE Pipe Extruder Machine SJ65 HDPE PPR Conduit Pipe Making Machine

Product Details:
Place of Origin: Qingdao China
Brand Name: WingsPlastic
Certification: CE
Model Number: SJ65/33
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wooden Box or Film Packing
Delivery Time: 45 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10 sets

PE Pipe Extruder Machine SJ65 HDPE PPR Conduit Pipe Making Machine

Description
Condition: New Powder Condition: 380V/50HZ Or Customized
Capacity: 150-220kg/h Or Customized Pipe Diameters: 20-110mm Or Customized
Suitable Materials: HDPE PPR LDPE LLDPE
High Light:

50HZ PE Pipe Extruder Machine

,

PE Pipe Extruder Machine SJ65

,

HDPE Pvc Conduit Pipe Making Machine

China PE Pipe Extrusion Line SJ65 , HDPE PE Pipe Extruder Machine Factory



China PE Pipe Extrusion Line SJ65 , HDPE Pipe Machine Factory
Qingdao Wings Plastic Technology Co., LTD., specializing in the production of PE plastic pipe production line, PE pipe extrusion machine.
What HDPE pipe application?
PE pipe general use polyethylene, and then aggregation, and so it is a kind of thermoplastic resin.Although it has good resistance of low temperature, stable chemical performance, and can resist most of the acid and alkali corrosion , but its heat resistance and aging resistance is not so good.
PE pipe production line, what is it?
PE pipe production line, it is mainly used to produce PE pipe, it is mainly by the control system, extruder, head, sizing and the cooling system, tractor, planetary cutting device and double rack, etc. Of these, the main characteristic is simple and convenient operation, and high degree of automation, can be continuous production.
Pipe range 16-63mm 20-110mm 75-160mm 90-250mm 110-315mm 160-450mm 315-630mm 500-800mm
Extruder ¢45mm ¢60mm ¢75mm ¢75mm ¢90mm ¢90mm ¢120mm ¢150mm
Extruder power AC30kw DC75kw DC110kw DC110kw DC160kw DC160kw DC280kw DC335kw
Extrusion capacity 60-100kg 100-150kg 250-300kg 250-300kg 350-400kg 350-400kg 650-700kg 850-900kg
Max. production speed 10m/min 6m/min 6m/min 6m/min 3 m/min 1.2m/min 0.9m/min 0.7m/min











PE Pipe Extruder Machine SJ65 HDPE PPR Conduit Pipe Making Machine 0

Based on the high quality of high speed, high yield.
The design concept of plasticizing with low temperature, to ensure high quality products.
High torque output, large thrust bearing.
For high strength alloy steel gear, axis, carburizing, grinding processing.
High hardness, high smoothness and low noise.
PLC intelligent control, which can realize linkage between the main auxiliary machinery.
The screw is 38 crmoal/A nitride material handling, wear-resisting.
Strict temperature control precision, air and water cooling.
Unique design of into the mouth with perfect water cooling device.
Screw barrel with groove feeding in the bottom, has enhanced feed functions, guarantee for the high speed and high yield extrusion.



PE Pipe Extruder Machine SJ65 HDPE PPR Conduit Pipe Making Machine 1
