Plastic HDPE Pipe Extruder Machine HDPE Single Wall Corrugated Pipe Extrusion Machine

Certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
I'm Online Chat Now

Plastic HDPE Pipe Extruder Machine HDPE Single Wall Corrugated Pipe Extrusion Machine

Plastic HDPE Pipe Extruder Machine HDPE Single Wall Corrugated Pipe Extrusion Machine
Plastic HDPE Pipe Extruder Machine HDPE Single Wall Corrugated Pipe Extrusion Machine
Plastic HDPE Pipe Extruder Machine HDPE Single Wall Corrugated Pipe Extrusion Machine Plastic HDPE Pipe Extruder Machine HDPE Single Wall Corrugated Pipe Extrusion Machine Plastic HDPE Pipe Extruder Machine HDPE Single Wall Corrugated Pipe Extrusion Machine Plastic HDPE Pipe Extruder Machine HDPE Single Wall Corrugated Pipe Extrusion Machine Plastic HDPE Pipe Extruder Machine HDPE Single Wall Corrugated Pipe Extrusion Machine Plastic HDPE Pipe Extruder Machine HDPE Single Wall Corrugated Pipe Extrusion Machine Plastic HDPE Pipe Extruder Machine HDPE Single Wall Corrugated Pipe Extrusion Machine

Large Image :  Plastic HDPE Pipe Extruder Machine HDPE Single Wall Corrugated Pipe Extrusion Machine

Product Details:
Place of Origin: Qingdao China
Brand Name: WingsPlastic
Certification: CE
Model Number: SJ45/33
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wooden Box or Film Packing
Delivery Time: 45 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10 sets

Plastic HDPE Pipe Extruder Machine HDPE Single Wall Corrugated Pipe Extrusion Machine

Description
Condition: New Powder Condition: 380V/50HZ Or Customized
Capacity: 40-80kg/h Or Customized Pipe Diameters: 10-50mm Or Customized
Suitable Materials: HDPE LDPE EVA PVC PA
High Light:

Plastic HDPE Pipe Extruder Machine 50HZ

,

HDPE Single Wall Corrugated Pipe Extrusion Machine

,

50HZ Single Wall Corrugated Pipe Extrusion Machine

Plastic HDPE single wall corrugated pipe extruder machine made in China

Qingdao Wings Plastic Technology Co.,Ltd pipe equipment:

The single wall corrugated pipe machine can extrude PP, PE. PVC. EVA AND PA corrugated pipe. It is high intensity, good flexibility and use in the electric thread-passing pipes, circuit of machine tool. protective pipe so flight.

Plastic single-wall corrugated pipes have feathers of high temperature resistance,resistant to corrosion and abrasion,high intensity,good flexibility,etc.

They are widely used in fields of auto wire, electric thread-passing pipes, circuit of machine tool, protective pipes of lamps and lanterns wire, tubes of air conditioner and washing machine, etc.

We have the confidence to say that we are the best manufacturer for single wall corrugated pipe extrusion machine. We use gear driven and could produce the 20mm diameter corrugated pipe with 20m/min speed.

We are the only one company which has nature technology for gear driven single wall corrugated pipe machine in China, it is water and air cooling system. This technology is different with old chain driven technology with only air cooling technology which is only 5-6m/min extrusion speed.



Model SJ-30 SJ-45 SJ-65
Pipe diameter (mm) 4.5-9 9-32 32-50
L/D 30:1 28:1 30;1
Motor power (kw) 4 11 8.5
Pair of modules 38 42 52
Output ( kg/h ) 10 40 80
Prodcution speed 6-10 12-20 12-20

Plastic HDPE Pipe Extruder Machine HDPE Single Wall Corrugated Pipe Extrusion Machine 0
