1200mm Plastic Mat Making Machine PVC Door Mat Making Machine Cushion Mat

Certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
I'm Online Chat Now

1200mm Plastic Mat Making Machine PVC Door Mat Making Machine Cushion Mat

1200mm Plastic Mat Making Machine PVC Door Mat Making Machine Cushion Mat
1200mm Plastic Mat Making Machine PVC Door Mat Making Machine Cushion Mat 1200mm Plastic Mat Making Machine PVC Door Mat Making Machine Cushion Mat 1200mm Plastic Mat Making Machine PVC Door Mat Making Machine Cushion Mat 1200mm Plastic Mat Making Machine PVC Door Mat Making Machine Cushion Mat 1200mm Plastic Mat Making Machine PVC Door Mat Making Machine Cushion Mat 1200mm Plastic Mat Making Machine PVC Door Mat Making Machine Cushion Mat

Large Image :  1200mm Plastic Mat Making Machine PVC Door Mat Making Machine Cushion Mat

Product Details:
Place of Origin: Qingdao China
Brand Name: WingsPlastic
Certification: CE
Model Number: SJ100/30
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wooden Box or Film Packing
Delivery Time: 45 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10 sets

1200mm Plastic Mat Making Machine PVC Door Mat Making Machine Cushion Mat

Description
Condition: New Powder Condition: 380V/50HZ Or Customized
Capacity: 500kg/h Or Customized Mat Width: 1200mm
Suitable Materials: PVC Powder Speed: 1-4m/min
Screw: Single Screw HS Code: 84772090
Origin: Qingdao China After-sales Service: 1 Year
High Light:

160mm Plastic Mat Making Machine

,

plastic mat manufacturing machine 50MM

,

160mm PVC Door Mat Making Machine

PVC Door Mat Coil Cushion Mat Making Machine Production Line



  The plastic coil carpet produced by the PVC coil mat production line, also known as the Polomei floor mat, is formed by combining plastic coil and foam film in one go. The product has the advantages of softness, aging resistance, easy cleaning, and convenient use. It is mainly used in shops, public places, homes, hospitals, elevators, stairs, fitness centers, and office spaces. The product is made of environmentally friendly PVC material, with a bright and long-lasting color that is not easily faded. Silk loop foot pad with spring row design, soft and comfortable to step on, easy to clean. The floor mat equipment produced by our company meets the needs of most customers and has been checked out for foreign markets, exported to India and other countries.



  The production line for PVC coil floor mats mainly consists of PVC coil extrusion equipment, PVC sheet extrusion equipment, sizing device, roller cooling device, traction device, and shear device. The spray extrusion equipment and the bottom plate extrusion equipment are placed in sequence and connected to the size measurement device. The cooling device after the device is sequentially glued is equipped with a row of rollers, a traction device, and a shear device; The spinneret extrusion equipment includes a sequentially placed spinneret extruder, a rotating mold, a screen cooling device drying device, a screen impregnation device, and a glue coating device. The spinning machine is equipped with at least two extruders, and there is an extrusion nozzle between the machine and the hydraulic screen changing device of the spinning mold. A wire plate is set between the spinneret mold and the screen cooling device.





Production Flow:

PVC mixing--Spiral loading into coil mat extruder--Extruder melt--Filter--Extrusion Die--Infrared heating--Forming water tank--First oven--Glue units--Second oven--Haul off and trimming--winding--packing





1200mm Plastic Mat Making Machine PVC Door Mat Making Machine Cushion Mat 0
Plastic PVC Coil Loop Carpet Manufacturing Machine / PVC Coil Carpet Roll Producing Plant



Name Extruder Backing Materials Mat width Power Condition Request Output Machinery Length
Single Color 120/30
1set
EPVC Foaming 1200mm 300kw 500kg/h 50meter
Two Color 100/30
2 sets
EPVC Foaming 1200mm 300kw 500kg/h 50meter
