HDPE PPR PP Plastic Pipe Extruder Machine Plastic Water Pipe Manufacturing Machine

Certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
I'm Online Chat Now

HDPE PPR PP Plastic Pipe Extruder Machine Plastic Water Pipe Manufacturing Machine

HDPE PPR PP Plastic Pipe Extruder Machine Plastic Water Pipe Manufacturing Machine
HDPE PPR PP Plastic Pipe Extruder Machine Plastic Water Pipe Manufacturing Machine
HDPE PPR PP Plastic Pipe Extruder Machine Plastic Water Pipe Manufacturing Machine HDPE PPR PP Plastic Pipe Extruder Machine Plastic Water Pipe Manufacturing Machine HDPE PPR PP Plastic Pipe Extruder Machine Plastic Water Pipe Manufacturing Machine HDPE PPR PP Plastic Pipe Extruder Machine Plastic Water Pipe Manufacturing Machine

Large Image :  HDPE PPR PP Plastic Pipe Extruder Machine Plastic Water Pipe Manufacturing Machine

Product Details:
Place of Origin: Qingdao China
Brand Name: Wings Plastic
Model Number: SJ65/33
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wooden Box or Film Packing
Delivery Time: 60 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 sets

HDPE PPR PP Plastic Pipe Extruder Machine Plastic Water Pipe Manufacturing Machine

Description
Screw L/D Ratio: 33:1 Screw Speed: 0-93rpm
Material: PP PE PPR Control System: PLC
Warranty: 1 Year Product Name: HDPE Pipe Extruder Machine
Cooling Method: Air/Water Dimension: Customized
High Light:

PLC Water Pipe Manufacturing Machine

,

PPR Water Pipe Manufacturing Machine

,

93 Rpm Plastic Pipe Extruder

Product Description:

HDPE PPR PP Plastic Pipe Extruder Machine Plastic Water Pipe Manufacturing Machine

We could produce various pp pe pvc extruder machine, like plastic pipe extruder, pp meltblow fabric extruder, pp sheet / pp strap extruder etc.
HDPE Communication Tube And Bundle Pipe Making Machine / Extrusion Line
HDPE Communication pipe machine have two system, one is HDPE microduct tube extrusion line, one is HDPE communication bundle pipe extrusion line. And the bundle pipe could be spiral corrugated pipe (COD pipe) or polygon pipe system.
Machinery equipment List:
  Automatic feeder, SJ65/33 Extruder. SJ25/25 Markline extruder, Core pipe die, Vacuum tank, water tank, haul-off machine, coiler
II. Common information of Machine Line
1. In view of operation safety, machine equipped with:
* E-stop switch;
* Control system to prevent machine from damaged at abnormal condition;
* Flash lamp and voice show machine is under abnormal running condition;
* The parts which probably cause damage to operation staff are all designed with protection.

2. The following technical documents included in the content of purchasing object:
* Installation layout diagram of machines;
* Circuit diagram of machines;
* Operation manual of machines;
* Certificate of machine quality;
* Certificate of machine warranty by supplier;
* Spare parts (refer to spare parts list).


3. Name and model : SJ65/33 HDPE tube extrusion line
* Output: Max 160 ± 10%Kg/h, expected producing speed: 0–100 m/min;
* Environment: Indoor, humidity 0.85, no condensation point, temperature<=40℃;
* Power supply: 380V 50HZ, 3-phase 4wires; Install power <=160KW;
* Circulation water flow: 12-14.0m3/h;
* Compressed air: 0.6-0.7Mpa.
* Operation directio

Features:

  • Raw material: HDPE PP PPR
    * Color of pipe: Customized
    * Size of pipe: OD20-110mm
    * Eccentricity : <=0.10
    * Internal and external surface of pipe should be smooth and single color, should be uniform wall thickness, no manufacturing defect and air bubble, shrinkage, crack, non-uniformity etc.

Technical Parameters:



Extruder Model
Motor Power
Output
Pipe Diameter
Production Speed
WSSJ70/32
37KW
150kg/h
16-63mm
2-20m/min
WSSJ65/33
37 kW
150kg/h
16-110 mm
2-20 m/min
WSSJ90/33
132KW
500kg/h
125-400mm
2-20m/min
Also, these parameters just for reference,we also need to confirm the pipe diameter and output capacity first,and then we will give you a complete plan.


Applications:

Plastic Pipe Extruder Machine - Perfect Solution for PVC and PP Single Wall Corrugated Pipes
Brand Name: Wings Plastic
Model Number: SJ65/33
Place of Origin: Qingdao, China
Introduction

Plastic Pipe Extruder Machine, also known as PVC single wall corrugated pipe extruder or PP single wall corrugated conduit pipe production line, is a highly efficient and versatile machine used for producing single wall corrugated pipes made of PVC or PP materials.

Application

This machine is widely used in various industries such as construction, telecommunications, and automotive for the production of PVC and PP single wall corrugated pipes. These pipes are commonly used for cable protection, drainage systems, and as electrical conduits.

Features
  • Customized dimensions to meet specific production requirements
  • Equipped with a powerful 3kw vacuum pump for efficient pipe production
  • Advanced PLC control system for precise and easy operation
  • Variable screw speed range of 0-93rpm for different pipe sizes and materials
  • Screw L/D ratio of 33:1 for optimal plastic melting and extrusion
Benefits
  • High production capacity and efficiency
  • Durable and long-lasting machine with low maintenance
  • Flexible and versatile for different pipe sizes and materials
  • Easy to operate and control for improved productivity
  • Produces high-quality single wall corrugated pipes with smooth inner and outer surfaces
Usage Scenario

Imagine a construction site where workers are installing a new drainage system. The pipes used for this system need to be durable, corrosion-resistant, and easy to install. This is where our Plastic Pipe Extruder Machine comes in. With its high-speed screw and advanced control system, it can produce PVC or PP single wall corrugated pipes in custom sizes to fit the specific needs of the construction project. The smooth inner and outer surface of these pipes ensures efficient water flow and prevents blockages, making them the perfect solution for drainage systems.

Another scenario is in a telecommunication company where they need to protect their underground cables from damage. Our Plastic Pipe Extruder Machine can produce high-quality corrugated pipes with precise dimensions to fit the cables perfectly. These pipes are lightweight, easy to install, and provide excellent protection to the cables, making them ideal for this application.

Conclusion

In conclusion, the Wings Plastic Pipe Extruder Machine is a reliable and efficient solution for producing PVC and PP single wall corrugated pipes. With its advanced features and customizable options, it can cater to the diverse needs of different industries and applications. Trust Wings Plastic for all your single wall corrugated pipe production needs!



Support and Services:

Technical Support and Service for Plastic Pipe Extruder Machine
Introduction

The Plastic Pipe Extruder Machine is a state-of-the-art equipment used for manufacturing various types of plastic pipes. It offers high efficiency, precision, and reliability in the extrusion process, making it a popular choice among industries.

Technical Support

We understand that your production process depends on the smooth functioning of the Plastic Pipe Extruder Machine. That's why our team of experienced technicians is available 24/7 to provide technical support for any issues or queries you may have.

Our technical support includes:

  • Installation and setup of the machine
  • Troubleshooting and maintenance
  • Training for operators and maintenance staff
  • Upgrades and customization
Service

We are committed to providing excellent service to our customers. Our service team is equipped with the necessary skills and tools to ensure the smooth operation of your Plastic Pipe Extruder Machine.

Our service includes:

  • Regular maintenance and inspections
  • Emergency repairs and replacement of parts
  • On-site technical support
  • Spare parts supply
Customer Satisfaction

Our goal is to ensure 100% customer satisfaction with our technical support and service. We value your feedback and continuously strive to improve our services to meet your needs.

Contact Us

For any technical support or service requests, please don't hesitate to contact us. Our team will be happy to assist you and ensure the smooth operation of your Plastic Pipe Extruder Machine.

Email: support@plasticpipeextrudermachine.com

Phone: +1 (555) 123-4567



Packing and Shipping:

Plastic Pipe Extruder Machine - Packaging and Shipping

Our Plastic Pipe Extruder Machine is carefully packaged and shipped to ensure its safe arrival at your doorstep.

Packaging

The machine is first wrapped in a protective layer of bubble wrap to prevent any damage during transportation. It is then placed in a sturdy wooden crate for extra protection.

Shipping

We offer both sea and air shipping options for our customers, depending on their preference and urgency of delivery. Our experienced logistics team will ensure that your machine is shipped using the most reliable and efficient methods.

Delivery Time

The delivery time for our Plastic Pipe Extruder Machine may vary depending on your location and chosen shipping method. We will provide you with an estimated delivery time upon confirmation of your order.

Customs and Duties

Please note that any customs or import duties are the responsibility of the buyer. We will provide all necessary documents to facilitate customs clearance, but any additional charges incurred will be the responsibility of the buyer.

For any further questions or concerns about our Packaging and Shipping process, please do not hesitate to contact us. We are committed to providing our customers with the best service possible.



FAQ:

  • Q: What is the brand name of this product?
  • A: The brand name of this product is Wings Plastic.
  • Q: What is the model number of this product?
  • A: The model number of this product is SJ65/33.
  • Q: Where is this product made?
  • A: This product is made in Qingdao, China.
  • Q: What is the main function of this product?
  • A: The main function of this product is to extrude plastic pipes.
  • Q: What type of plastic can this machine process?
  • A: This machine can process various types of plastic such as PVC, PE, PP, etc.
  • Q: How long does it take to change the mold for different pipe sizes?
  • A: It takes approximately 20-30 minutes to change the mold for different pipe sizes.
