Pe Pipe Extrusion Line Plastic Ppr Hdpe Pipe Making Machine

Certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
I'm Online Chat Now

Pe Pipe Extrusion Line Plastic Ppr Hdpe Pipe Making Machine

Pe Pipe Extrusion Line Plastic Ppr Hdpe Pipe Making Machine
Pe Pipe Extrusion Line Plastic Ppr Hdpe Pipe Making Machine Pe Pipe Extrusion Line Plastic Ppr Hdpe Pipe Making Machine Pe Pipe Extrusion Line Plastic Ppr Hdpe Pipe Making Machine

Large Image :  Pe Pipe Extrusion Line Plastic Ppr Hdpe Pipe Making Machine

Product Details:
Place of Origin: CHINA
Brand Name: WINGS
Certification: CE ISO
Model Number: SJ
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 15000-25000 per set
Packaging Details: woode case and container
Delivery Time: 30 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 20 sets per month

Pe Pipe Extrusion Line Plastic Ppr Hdpe Pipe Making Machine

Description
Screw Material: 38CrMoAlA Screw L/D Ratio: 33:1
Raw Material: PP PE Granules Inverter: Delta Brand
Contactor: Siemens Contactor Switch: CHNT
Screw Speed: 94 Rpm Screw Diameter: 65mm
Temperature Controller: Omron Brand Application: Pipe
High Light:

94 rpm Pipe Extrusion Line

,

65mm Pe Pipe Extrusion Line

,

PLC Ppr Pipe Making Machine

PE PP Plastic Pipe Extruder Machine is widely used in various countries around the world. Some of the target countries for this type of extruder machine include China, the United States, Germany, India, Brazil, and many others. These countries have a significant demand for plastic pipes in industries such as construction, agriculture, telecommunications, and infrastructure development.

Production Process:
1. Material Feeding: The granules are fed into the extruder machine through a hopper. The machine's feeding system ensures a steady supply of material to the extrusion process.
2. Extrusion: Inside the extruder, the granules are heated and melted using barrel heaters and screw rotation. The molten plastic is then forced through a die head, which shapes it into a pipe of the desired diameter and thickness.
3. Cooling and Sizing: The newly formed pipe passes through a cooling system, which rapidly cools it down to achieve dimensional stability. Sizing sleeves or vacuum sizing tanks help control the outer diameter of the pipe and ensure uniformity.
4. Haul-off and Cutting: The pipe is then pulled by a haul-off unit at a constant speed to maintain consistency. Finally, a cutting unit precisely cuts the pipe into desired lengths, and the finished pipes are collected for further processing or packaging.

Features of the Machine:
1. Versatility: The PE PP Plastic Pipe Extruder Machine is capable of processing both PE and PP materials, offering flexibility in manufacturing pipes for various applications.
2. High Production Efficiency: The machine is designed for high-speed production, enabling the manufacture of a large volume of pipes in a short period. This improves productivity and meets the demands of a rapidly growing market.
3. Precise Control and Quality: The extruder machine provides precise control over temperature, pressure, and speed, ensuring consistent quality and uniformity of the pipes produced. This control allows manufacturers to meet industry standards and customer specifications.
4. Energy Efficiency: The machine is designed to optimize energy consumption by utilizing efficient heating and cooling systems. This reduces operational costs and promotes sustainability.
5. Easy Operation and Maintenance: The PE PP Plastic Pipe Extruder Machine features user-friendly controls and a simple interface, making it easy to operate. It also requires minimal maintenance, ensuring uptime and reducing maintenance costs.

Pe Pipe Extrusion Line Plastic Ppr Hdpe Pipe Making Machine 0
