Product Details:
|
| Condition: | New | Powder Condition: | 380V/50HZ Or Customized |
|---|---|---|---|
| Capacity: | 50-150kg/h Or Customized | Pipe Diameters: | Customized |
| Suitable Materials: | EVA LLDPE Materials | Speed: | 1-20m/min |
| Highlight: | Microduct Plastic Pipe Extrusion Line,150kg/h Plastic Pipe Extrusion Line COD Bundle,Bundle Corrugated Tube Production Line 150kg/h |
||
PE Bundle Microduct Communication Pipe Extrusion Line
HDPE Communication pipe machine have two system, one is HDPE microduct tube extrusion line, one is HDPE communication bundle pipe extrusion line. And the bundle pipe could be spiral corrugated pipe (COD pipe) or polygon pipe system.
Machinery equipment List:
1. Core pipe system include: Automatic feeder, SJ65/33 Extruder. SJ25/25 Markline extruder, Core pipe die, Vacuum tank, water tank, haul-off machine, coiler
2. Bundle Pipe system include: Uncoiler for core pipe, guiding device, coating die, 65/33 Extruder, Vacuum tank, haul off machine, coiler
Machinery Basic Informations:
| Pipe Range | Extruder Model | Main Motor | Output | Speed |
| Core Pipe 6-20mm | SJ55/33 | 22kw | 80kg/h | 1-20m/min |
|
Core Pipe 10-32mm |
SJ55/33 | 30kw | 120kg/h | 1-30m/min |
| Bundle Pipe | SJ70/32 | 30kw | 120kg/h | 0.5-6m/min |
