Plastic EVA Pipe Production Machine Vacuum Cleaner Corrugated Pipe Machine Line

Plastic EVA Pipe Production Machine Vacuum Cleaner Corrugated Pipe Machine Line
Plastic EVA Pipe Production Machine Vacuum Cleaner Corrugated Pipe Machine Line
Plastic EVA Pipe Production Machine Vacuum Cleaner Corrugated Pipe Machine Line Plastic EVA Pipe Production Machine Vacuum Cleaner Corrugated Pipe Machine Line Plastic EVA Pipe Production Machine Vacuum Cleaner Corrugated Pipe Machine Line Plastic EVA Pipe Production Machine Vacuum Cleaner Corrugated Pipe Machine Line Plastic EVA Pipe Production Machine Vacuum Cleaner Corrugated Pipe Machine Line Plastic EVA Pipe Production Machine Vacuum Cleaner Corrugated Pipe Machine Line

Large Image :  Plastic EVA Pipe Production Machine Vacuum Cleaner Corrugated Pipe Machine Line

Product Details:
Place of Origin: Qingdao China
Brand Name: WingsPlastic
Certification: CE
Model Number: SJ65/30
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wooden Box or Film Packing
Delivery Time: 45 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10 sets

Plastic EVA Pipe Production Machine Vacuum Cleaner Corrugated Pipe Machine Line

Description
Condition: New Powder Condition: 380V/50HZ Or Customized
Capacity: 80kg/h Or Customized Pipe Diameters: 30-70mm Or Customized
Suitable Materials: EVA LLDPE Materials Speed: 1-5m/min
Screw: Single Screw HS Code: 84772090
Origin: Qingdao China After-sales Service: 1 Year
High Light:

LLDPE Hdpe Pipe Production Machine

,

Hdpe Pipe Production Machine Corrugated 80kg/h

,

LLDPE Corrugated Pvc Pipe Machine Line

Chinese Best Plastic Corrugated EVA LLDPE Vacuum Cleaner Pipe Extrusion Line

The machine could produce eva vacuum cleaner hose,also swimming pool spiral hose machine

EVA LLDPE Pipe Instruction :

  EVA LLDPE spiral pipe is a kind of pipe used as vacuum cleaner pipe or swimming pool cleaning pipe. It is made by EVA and LLDPE mixed materials, spiral corrugated structure.

 The pipe could be made into different colors and different diameters. Mainly popular size is ID32mm to ID50mm.

 The spiral corrugated pipe has high elasticity ,high flexibility, ,UV resistance and long servie time. It is very popular and high quality choice for cleaning feild.

Plastic EVA Pipe Production Machine Vacuum Cleaner Corrugated Pipe Machine Line 0

The eva vacuum cleaner hose extrusion line Production Flow:

Vacuum Feeder--Extruder melt--Extrusion moulds--Water tank--Dewatering fan--Forming unit with Glue extrusion--Transport rollers--Automatic cutter--Stacking Unit



The machinery instruction:

 Qingdao Wings Plastic Technology Co.,Ltd is the best manufacturer for eva lldpe spiral corrugated pipe machine with Rich experience, professional technology, excellent after-sales service, high quality production.

 The machine includes: single screw extruder SJ65, single screw extruder SJ35, moulds, water tank with dewatering units, forming units, glue extruder, traction rollers, servo motor cutter, stacker, PLC electric control units.

 The max extrusion speed could be 4-6m/min according diameters,output will be 60-80kg/h. And two colors machine could produce single color and double color pipe both.

 Welcome to contact us by email or whatsapp for more details. :)



The eva vacuum cleaner hose extrusion line equipment list:

Automatic feeding system 1set
Single screw extruder for hose 1set
Single screw extruder for glue 1set
Die head for eva profile 1set
Eva hose forming system 1set
Water cooling tank 1set
Cutter machine 1set
Stacker 1set
Crusher 1set
Materials mixer 1set
Electric control system 1set

Plastic EVA Pipe Production Machine Vacuum Cleaner Corrugated Pipe Machine Line 1
