Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line

Certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
China Qingdao Wings Plastic Technology Co.,Ltd certification
I'm Online Chat Now

Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line

Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line
Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line
Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line

Large Image :  Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line

Product Details:
Place of Origin: QINGDAO CHINA
Brand Name: WINGS PLASTIC
Certification: CE
Model Number: SJ65/33
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wooden Box or Film Packing
Delivery Time: 45 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 sets

Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line

Description
Control System: PLC & Touch Screen Condition: New
Extruder: Single-screw Material: HDPE PPR LDPE LLDPE
Power Supply: AC380V/50Hz/3Phase Screw Diameter: 20-110mm
Screw L/D Ratio: 30:1 Capacity: 150-220kg/h Or Customized
Highlight:

Single Screw Plastic Pipe Extruder

,

HDPE Water Pipe Extruder Machine

,

AC380V Gas Pipe Production Line

Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line

Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line 0

This machine is used for producing water / gas supply, and sewage and drain pipe, also undergroud pipes. The Materials could be HDPE, PP,PPR materials. HDPE,PP,PPR pipe is from same machine.



Description of PE Pipe Extrusion Line



This PE Pipe Extrusion Line can be used in PE Large Diameter Gas and Water Pipe which have excellent stiffness and flexibility, heat resistance, aging resistance, high mechanical strength, resistance of environmental stress cracks, resistance to creep deformation, heat-linkage, and so on.

So, this pipe production line is a preferred gas and water pipe for ductwork system between city and its suburb.

Large diameter HDPE pipes start to play very important role in the city water and gas supply systems.



Single Screw Plastic Pipe Extrusion Line HDPE Pipe Production Line 0

Technical Parameter for pe pipe production machine



Pipe Range 16-63mm 20-110 75-160 90-250 110-315 160-450 315-630mm 500-800mm
Extruder ¢45mm ¢60mm ¢75mm ¢75mm ¢90mm ¢90mm ¢120mm ¢150mm
Extruder Power AC30KW DC75KW 110KW 110KW 160KW 160KW 280KW 335KW
Extrusion Capacity(kg) 60-100 100-150 250-300 250-300 350-400kg 350-400kg 650-700kg 850-900kg
Max. Speed 10m/min 6m/min 6m/min 6m/min 3m/min 1.2m/min 0.9m/min 0.7m/min




Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line 2Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line 3

Single Screw Plastic Pipe Extruder Machine HDPE Water Pipe Gas Pipe Production Line 4
